Oldtimer picture gallery. Cars. KdF-Wagen.
KdF-Wagen.
Years of production: 1938-1939
Overall production: 630 units
4x2 rear-motor car
Body modifications:
2-door Limousine,
2-door Sonnenschein-Limousine,
2-door Cabriolet.
Engine: aircooled 24,5hp/3000rpm, aircooled
4-cyl. boxer OHV, 985cc
Bore/Stroke: 70/64 mm
Compression ratio: 5,8 : 1
Length: 4,20m, width: 1,55m, height: 1,55m
Wheelbase: 2400mm
Road clearance: 220mm (loaded, 4 pers. x 75kg + 50kg luggage)
Maximal ford depth: ?mm
Turning radius: ?m
Battery: 6 Volt by Bosch, 75 A*h
Carburetter: 1 downdraft Solex (26 VFJ?)
Clutch: dry single plate by Fichtel & Sachs
Gearbox: 4 forward 1 back
Ratios: I - 3,60, II - 2,07, III - 1,25, IV - 0,80, rear - 6,6
Rear axle ratio: ?
Front wheel track: 1250mm
Rear track: 1250mm
Front suspension: ?
Rear suspension: ?
Mechanical brakes on all wheels
Weight: 650 kg
Maximal speed: 105 km/h (highway)
Tyres: 4,5-16 inches (maximal - 5,25-16 inches)
Fuel tank capacity: 25 Ltr. + 3 Ltr. reserve (in the front part of the car)
Fuel consumption: ? Ltr./100km (highway)
Oil carter capacity: engine - 3 Ltr.
Price: 990 RM pre-pay 5RM mark a week added to special
KdF-Wagen-SparKarte, when full - go and buy. But nobody was in
time before WW2 beginning.
