Oldtimer gallery. Motorcycles. Izh-350.
25k 1 X 1950 photo of Izh-350
Izh-350

Years of production: 1946 - 1951
Overall production: 127090
Engine: 11,5hp/4000rpm, aircooled 1-cyl., 2-stroke, 346cc
Bore/Stroke: 72/85 mm
Compression ratio: 5,8 : 1
Length: 2110 mm, width: 710 mm, height: 925 mm (fuelled)
Wheelbase: 1355mm
Road clearance: 120 mm
Carburetter: K-40
Clutch: multi-disk oiled
Gearbox: 4-speed, hand- and foot controlled
Ratios: I - 4,32; II - 2,24; III - 1,40; IV - 1,00
Rear axle ratio: 2,33 (chain)
53k photo of Izh-350Pressed steel frame
Parallelogram front fork
Ignition: Battery ZMT-7, 6 Volt, 7 Ah
Generator: G-36, 45 Watt
Spark plug type and dimensions: ?
Interrupter clearance: ? mm
Chain
Shoe brakes
Weight fuelled unloaded: 156 kg
Engine weight: ?
Maximal speed: 90 km/h
Tyres: 3,25x19 inches
Tyre pressures (atmospheres): front - 1,5; rear - 1,8 (2,3 with passenger)
Fuel tank capacity: 15 Ltr.
Gearbox oil carter capacity: ? Ltr
Petrol consumption: 3,5 Ltr./100km under 50 km/h
235k photo of Izh-350 and 2 MoskvaFord passing depth: ? mm
Izh-350 is "2nd series" of DKW NZ350 which production line was moved to Izhevsk after WW2.

Photos are from:
Molotok.ru online auction, Russia.
Aleksei Rjazancev, Sankt-Peterburg, Russia.
